Odyssey Battery - PC680MJT

Odyssey Battery -PC680MJT

Whether for everyday or emergency use, today’s vehicles are loaded with more electronics than would have been imaginable just a few years ago. ODYSSEY batteries have been designed to keep up with the changes. Because their plates are made of pure virgin lead (unlike the lead alloy in most batteries), we can pack in more plates. And more plates mean more plate surface area, and much more power – twice the overall power and three times the life of conventional batteries – up to 400 cycles at 80% depth of discharge!
ODYSSEY batteries deliver the massive starting power, rapid recovery, and amazing deep cycling capability that today’s vehicles demand.

Dimensions:
Length: 185.42mm
Width: 78.74mm
Height (terminals included): 193.04mm
Height (container):170.87mm
Weight: 7.52 KG

Specifications:
Voltage: 12V
Pulse (5 second) Hot Cranking Amps (PHCA): 520A
Cold Cranking Amps (CCA): 170A
HCA: 350A
MCA: 280A
20Hr Nominal Capacity (Ah): 16Ah
10Hr Nominal Capacity (Ah): 16Ah
Reserve Capacity Minutes: 24 mins
Terminal: SAE
Torque Spec in-lbs (Nm max): N/A
Internal Resistance (mΩ): 7mΩ
Short Circuit (A): 1800A
Operating Temperature Range: -40°F / -40°C to 113°F / +45°C
Optimum Storage Temperature: 68°F / +20°C
